BB604/BB605
7
CIRCUIT BOARD
Component side
Pattern side
to BALANCER
to BATTERY
DC9V
to TREBLE
BASS
to M.VOLUME
to MID FREQ.
SWITCH
MID FREQ.
Jumper Wire (QC67200)
Note: See parts list for details of circuit board component parts.
Component side
Pattern side
EPA-QC67150-1 1
EPA-QC67150-2
