What to do if Yamaha Outboard Motor fuel management gauge shows incorrect fuel consumption?
If the fuel management gauge shows incorrect fuel consumption, the engine recognition might be wrong (especially for multi-applications). To fix this, default the engine number and turn the key switch on in order from the portside engine to re-memorize each engine number.
What to do if the Yamaha E60HWHD E60HWD gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or, if necessary, replace the gauge itself.
Why Yamaha E60HWHD E60HWD Outboard Motor illumination does not light?
If the illumination does not light, it could be due to a lack of electrical power or a damaged gauge. You should try replacing the fuse, connecting the couplers securely, replacing the damaged wire or hub, or replacing the gauge.
How to fix Yamaha Outboard Motor tachometer showing incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong (especially for multi-applications). To correct this, push the 'SET' button for 10 seconds to default the engine number, then memorize each engine number again.
What causes Yamaha E60HWHD E60HWD Outboard Motor fuel management gauge to show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting may be wrong (specifically for SQR Fuel mgt Gauge). Fill the tank with fuel, and set the correct fuel tank capacity.
What to do if Yamaha E60HWHD E60HWD Outboard Motor gauge shows “----”?
If the gauge displays '----', it indicates that the digital signal is not being received. Check that the couplers are securely connected and replace any damaged bus wires or hubs.
Why Yamaha E60HWHD E60HWD Speedometer or Comb. Speedometer & Fuel mgt gauge shows incorrect fuel level?
If the speedometer or combination speedometer & fuel management gauge shows an incorrect fuel level, the fuel sensor selection is likely wrong. Set up the fuel sensor to the correct resistance.
How to fix Yamaha E60HWHD E60HWD trim gauge showing incorrect position?
If the trim gauge shows an incorrect position, the initial position setting might be wrong, or the trim sender could be damaged. Put the motor in the fully trimmed-in position and reset the initial (zero) trim angle. If that doesn't work, replace the trim sender.
Why Yamaha E60HWHD E60HWD gauge operates unstably?
If the gauge operates unstably, it could be because a resistor is not connected to the ending hubs. Connect the gray 6-pin cap to the ending multi-hubs.
What causes Yamaha E60HWHD E60HWD Outboard Motor gauge response to be poor or down?
If the gauge response is poor or down, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Try replacing the unit or removing the heavy signal output unit.
Step-by-step procedure for safely removing the outboard motor from its steel frame crate.
Instructions for properly mounting the outboard motor onto the boat transom for optimal performance.
Guidance on choosing the correct propeller pitch and diameter for optimal engine speed and performance.
Procedures for adjusting throttle cable free-play for push-to-open and pull-to-open systems.
Details features and electrical functions of the multi-function tiller handle for various engines.
Procedures for installing gauges, including mounting location, angle, and wire harness connection.
Essential for outboard performance monitoring, it displays engine speed for efficient operation.
Monitors engine speed, includes hour meter, trim meter, and oil warning indicator.
Measures boat speed via water impact force and can be calibrated for mph, km/h, or knots.
Wiring diagrams for fuel injected and HPDI engines (single, twin, triple engine configurations).
Procedure for initial setup required for proper gauge operation with multiple engines.
Table addressing common system or gauge issues, their causes, measures, and notes.
Guides on selecting a suitable battery, emphasizing compatibility with Yamaha's charging system.
Wiring instructions for isolator-equipped models and multi-engine installations.
Checklist for pre-delivery inspection to enhance customer satisfaction and ensure proper setup.
General| Horsepower | 60 hp |
|---|---|
| Starting System | Electric |
| Fuel Tank Capacity | N/A (External fuel tank) |
| Shaft Length | 508 mm (20 in) - E60HWD, 635 mm (25 in) - E60HWHD |
| Gear Ratio | 2.00 (26/13) |
