E
2-3
EMU00039
OPERATIONS OF CONTROLS
AND
OTHER FUNCTIONS
EMU01465
FUEL TANK
If your model included a portable fuel tank,
its parts and functions are as follows.
1 Fuel hose joint
2 Fuel meter (if equipped)
3 Fuel tank cap
4 Air vent screw (if equipped)
EMU00042
Fuel Hose Joint
This connector is provided for connecting or
disconnecting fuel hose.
EMU01533
Fuel meter
This meter is on the fuel hose connector. It
shows the approximate amount of fuel
remaining in the tank.
EMU00045
Fuel Tank Cap
This cap is for filling fuel. To remove it, turn
it counterclockwise.
EMU00046
Air Vent Screw
This screw is on the fuel tank cap. To loosen
it, turn it counterclockwise.
