What to do if Yamaha Outboard Motor fuel management gauge shows incorrect fuel consumption?
If the fuel management gauge shows incorrect fuel consumption, the engine recognition might be wrong (especially for multi-applications). To fix this, default the engine number and turn the key switch on in order from the portside engine to re-memorize each engine number.
What to do if the Yamaha F30AWHD Outboard Motor gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or, if necessary, replace the gauge itself.
Why Yamaha F30AWHD illumination does not light?
If the illumination does not light, it could be due to a lack of electrical power or a damaged gauge. You should try replacing the fuse, connecting the couplers securely, replacing the damaged wire or hub, or replacing the gauge.
How to fix Yamaha Outboard Motor tachometer showing incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong (especially for multi-applications). To correct this, push the 'SET' button for 10 seconds to default the engine number, then memorize each engine number again.
What causes Yamaha F30AWHD fuel management gauge to show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting may be wrong (specifically for SQR Fuel mgt Gauge). Fill the tank with fuel, and set the correct fuel tank capacity.
What to do if Yamaha Outboard Motor gauge shows “----”?
If the gauge displays '----', it indicates that the digital signal is not being received. Check that the couplers are securely connected and replace any damaged bus wires or hubs.
Why Yamaha Outboard Motor Speedometer or Comb. Speedometer & Fuel mgt gauge shows incorrect fuel level?
If the speedometer or combination speedometer & fuel management gauge shows an incorrect fuel level, the fuel sensor selection is likely wrong. Set up the fuel sensor to the correct resistance.
How to fix Yamaha Outboard Motor trim gauge showing incorrect position?
If the trim gauge shows an incorrect position, the initial position setting might be wrong, or the trim sender could be damaged. Put the motor in the fully trimmed-in position and reset the initial (zero) trim angle. If that doesn't work, replace the trim sender.
Why Yamaha Outboard Motor gauge operates unstably?
If the gauge operates unstably, it could be because a resistor is not connected to the ending hubs. Connect the gray 6-pin cap to the ending multi-hubs.
What causes Yamaha F30AWHD gauge response to be poor or down?
If the gauge response is poor or down, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Try replacing the unit or removing the heavy signal output unit.
General| Engine Type | 4-Stroke, SOHC |
|---|---|
| Starting System | Electric |
| Gear Shift | F-N-R |
| Full Throttle RPM Range | 5000-6000 RPM |
| Displacement | 747 cc |
| Max Output | 30 hp |
| Fuel Induction System | EFI (Electronic Fuel Injection) |
| Recommended Fuel | Regular Unleaded |
| Ignition System | TCI |
| Shaft Length | 20 in |
| Trim Method | Power Trim |
| Exhaust | Through Prop Hub |
| Steering | Tiller |
Important safety warnings to prevent severe injury or death.
Steps for uncrating the outboard motor from a steel frame.
Instructions for correctly mounting the outboard motor onto the boat transom.
Instructions for installing the remote oil tank for 2-stroke V4 and V6 engines.
Details on Yamaha propeller types and their specifications.
Guidance on selecting the appropriate propeller for various applications.
Application guide for 2009 Yamaha propellers by engine size and type.
Details on different Yamaha remote control models and their applications.
Features and applications of the multi-function tiller handle.
Specifications, applications, and dimensions of analog tachometers.
Specifications, applications, and dimensions of digital tachometers.
Applications, dimensions, and setup for boat speedometers.
Functions, applications, dimensions, and setup for fuel management gauges.
List of Yamaha models compatible with digital network gauges.
Wiring diagrams for various digital network gauge configurations.
Common troubleshooting steps for system and gauge issues.
Guidelines for selecting the correct battery capacity and type.
