3-10
REMOTE CONTROL APPLICATIONS
6X6 REMOTE CONTROL (FOR F250, F300, F350 [Digital Electronic Control])
Exclusive binnacle remote control unit, which requires no mechanical remote control cables.
The throttle and shift operations are electrically controlled by Digital Network System, which will
obtain smoother remote control operation without cable friction.
Rigging has been simplified, because the mechanical cable adjustment is not required.
These remote control units cover single, twin and triple engine application.
Requires Digital Network Gauge (6Y8) for monitoring the engine.
* For further information, see the installation (P/N: 6X6-2819K-S1, 6X6-2819K-J0, 6X6-2819K-K0 and/or 6X6-
28107-P1) supplied with package.
Ref.
No.
Part No.
Variation
code
Engine
Single
station
Dual station
Remarks
Single Twin Triple Main 2nd
1
6X6-48205-00 A 1 1 STD (unaccepted for dual-station)
6X6-48205-10 C 1 1 1
6X6-48205-20 G 1 1
2
6X6-48207-00 B 1 1 STD (unaccepted for dual-station)
6X6-48207-10 D 1 1 1
6X6-48207-20 H 1 1
3
6X6-48208-20 F 1 1 1
6X6-48208-30 K 1 1
123

Yamaha F40BWHT Specifications

General

Horsepower	40 hp
Displacement	747 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Starting System	Electric
Full Throttle RPM Range	5000-6000 RPM
Gear Shift	F-N-R
Shaft Length	20 in
Steering	Remote
Trim Method	Power Trim & Tilt
Exhaust	Through propeller
Engine Type	4-Stroke
Alternator Output	16 Amp
Recommended Fuel	Unleaded gasoline
Recommended Engine Oil	Yamalube 4M
Ignition System	TCI
Warranty	3 years
Fuel Tank Capacity	N/A (External)
