Yamaha F60F - Overheat-Alert Indicator; Digital Speedometer; Speedometer

Instruments and indicators
33
EMU26584
Overheat-alert indicator
If the engine temperature rises too high, the
alert indicator will start to blink. For further in-
formation on reading the indicator, see page
39.
ECM00053
Do not continue to run the engine if the
overheat-alert indicator is on. Serious en-
gine damage will occur.
EMU26603
Digital speedometer
This gauge shows the boat speed and other
information.
All segments of the display will light momen-
tarily after the main switch is turned on and
will return to normal thereafter.
EMU36062
Speedometer
The speedometer displays km/h, mph, or
knots, according to operator preference. Se-
lect the desired units of measurement by set-
ting the selector switch on the back of the
gauge. See the illustration for settings.
1. Low oil pressure-alert indicator
1. Overheat-alert indicator
ZMU01736
1
ZMU01737
1
1. Speedometer
2. Fuel gauge
3. Trip meter/clock/voltmeter
4. Alert indicator(s)
1. Cap
2. Selector switch (for speed unit)
3. Selector switch (for fuel sensor)
1
2
3
4
km/h
(km)
mph
(mile)
knots
(mile)
1234
ZMU07001
3
1
2
