4-5
4
To set the clock
1. Set the display to the clock mode.
2. Push the “ / ” button until the clock starts
flashing.
3. Set the hours by pushing the “H” button.
4. Set the minutes by pushing the “M” button.
5. Push the “ / ” button, and then release it to
start the clock.
EBU18050
Fuel gauge
The fuel gauge indicates the amount of fuel in the
fuel tank. When the needle reaches the red line, re-
fill the tank at the first opportunity.
TIP
If the ATV runs out of fuel, move the fuel cock lever
to the “RES” position. Approximately 4.5 L (1.19
US gal, 0.99 Imp.gal) of fuel will be remaining in
the tank.
EBU18061
Handlebar switches
1. Fuel gauge
2. Red line
1. Light switch “ / /OFF”
2. Start switch “”
3. Engine stop switch “ / ”
4. Override switch “OVERRIDE”
5. Horn switch “”
U37S60E0.book Page 5 Thursday, June 5, 2008 6:51 PM
