Yamaha Grizzly 700 FI User Manual

5-8
5
NOTE:
The low-pressure tire gauge is included as stan-
dard equipment. Make two measurements of the
tire pressure and use the second reading. Dust or
dirt in the gauge could cause the first reading to be
incorrect.
Set the tire pressure when the tires are cold. Set
the tire pressures to the following specifications:
EBU19830
Tire wear limit
Replace the tire when the tire groove decreases to
3 mm (0.12 in).
1. Low-pressure tire gauge
Recommended pressure:
Front
35.0 kPa (5.0 psi) (0.350 kgf/cm²)
Rear
30.0 kPa (4.3 psi) (0.300 kgf/cm²)
Minimum:
Front
32.0 kPa (4.6 psi) (0.320 kgf/cm²)
Rear
27.0 kPa (3.9 psi) (0.270 kgf/cm²)
Maximum:
Front
38.0 kPa (5.5 psi) (0.380 kgf/cm²)
Rear
33.0 kPa (4.8 psi) (0.330 kgf/cm²)
U3B410E0.book Page 8 Friday, April 14, 2006 9:13 AM
