Yamaha MOTIF ES6 Data List

Effect Parameter List
Reverb Block
HALL1 – PLATE, R3 HALL – R3 PLATE
WHITE ROOM – CANYON
LARGE HALL – RICH PLATE
Large Hall, Medium Hall: (Table No.25)
Warm Room, Woody Room: (Table No.26)
Rich Plate: (Table No.27)
For details, refer to the Effect Data Assign Table.
Chorus, Insertion A, B Block
THRU
HALL1 – PLATE
DELAY L, C, R
DELAY L, R
DELAY L, R (Stereo)
ECHO
CROSS DELAY
CONTROL DELAY 1 (MONO)
No. Parameter Range Value Table No.
01 Reverb Time 0.3s – 30.0s (0 – 69) 4
02 Diffusion 0 – 10 (0 – 10)
03 Initial Delay 0.1ms – 200.0ms (0 – 127) 5
04 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
05 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
11 Reverb Delay 0.1ms – 200.0ms (0 – 127) 5
12 Density 0 – 4 (0 – 4)
13 ER / Rev Balance E63>R – E=R – E<R63 (1 – 127)
14 Feedback High Damp 0.1 – 1.0 (1 – 10)
15 Feedback Level -63 – +63 (1 – 127)
No. Parameter Range Value Table No.
01 Reverb Time 0.3s – 30.0s (0 – 69) 4
02 Diffusion 0 – 10 (0 – 10)
03 Initial Delay 0.1ms – 200.0ms (0 – 127) 5
04 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
05 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
06 Width 0.5m – 30.2m (0 – 104) 11
07 Height 0.5m – 30.2m (0 – 104) 11
08 Depth 0.5m – 30.2m (0 – 104) 11
09 Wall Vary 0 – 30 (0 – 30)
11 Reverb Delay 0.1ms – 200.0ms (0 – 127) 5
12 Density 0 – 4 (0 – 4)
13 ER / Rev Balance E63>R – E=R – E<R63 (1 – 127)
14 Feedback High Damp 0.1 – 1.0 (1 – 10)
15 Feedback Level -63 – +63 (1 – 127)
No. Parameter Range Value Table No.
01 Reverb Time 0.3s – 18.0s/10.0s/26.0s (0 – 69) 25/26/27
02 Diffusion 0 – 10 (0 – 10)
03 Initial Delay 0.1ms – 200.0ms (0 – 127) 5
04 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
05 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
06 Room Size 0 – 31 (0 – 31)
07 High Ratio 0.1 – 1.0 (1 – 10)
08 Low Ratio 0.1 – 1.4 (1 – 14)
09 Decay 0 – 63 (0 – 63)
No. Parameter Range Value Table No.
01 Reverb Time 0.3s – 30.0s (0 – 69) 4
02 Diffusion 0 – 10 (0 – 10)
03 Initial Delay 0.1ms – 99.3ms (0 – 63) 5
04 HPF Cutoff Frequency 20Hz – 8.0kHz (0 – 52) 3
05 LPF Cutoff Frequency 1.0kHz – 20.0kHz (34 – 60) 3
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Reverb Delay 0.1ms – 99.3ms (0 – 63) 5
12 Density 0 – 4 (0 – 4)
13 ER / Rev Balance E63>R – E=R – E<R63 (1 – 127)
14 Feedback High Damp 0.1 – 1.0 (1 – 10)
15 Feedback Level -63 – +63 (1 – 127)
No. Parameter Range Value Table No.
01 Delay Time L 0.1ms – 1638.3ms (1 – 16383)
02 Delay Time R 0.1ms – 1638.3ms (1 – 16383)
03 Delay Time C 0.1ms – 1638.3ms (1 – 16383)
04 Feedback Time 0.1ms – 1638.3ms (1 – 16383)
05 Feedback Level -63 – +63 (1 – 127)
06 Delay Level C 0 – 127 (0 – 127)
07 Feedback High Damp 0.1 – 1.0 (1 – 10)
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
13 EQ Low Frequency 32Hz – 2.0kHz (4 – 40) 3
14 EQ Low Gain -12dB – +12dB (52 – 76)
15 EQ High Frequency 500Hz – 16.0kHz (28 – 58) 3
16 EQ High Gain -12dB – +12dB (52 – 76)
No. Parameter Range Value Table No.
01 Delay Time L 0.1ms – 1638.3ms (1 – 16383)
02 Delay Time R 0.1ms – 1638.3ms (1 – 16383)
03 Feedback Time 1 0.1ms – 1638.3ms (1 – 16383)
04 Feedback Time 2 0.1ms – 1638.3ms (1 – 16383)
05 Feedback Level -63 – +63 (1 – 127)
06 Feedback High Damp 0.1 – 1.0 (1 – 10)
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
13 – 16: Same as marked with *.
No. Parameter Range Value Table No.
01 Delay Time L 0.1ms – 1638.3ms (1 – 16383)
02 Delay Time R 0.1ms – 1638.3ms (1 – 16383)
03 Feedback Time L 0.1ms – 1638.3ms (1 – 16383)
04 Feedback Time R 0.1ms – 1638.3ms (1 – 16383)
05 Feedback Level -63 – +63 (1 – 127)
06 Feedback High Damp 0.1 – 1.0 (1 – 10)
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
13 – 16: Same as marked with *.
No. Parameter Range Value Table No.
01 Delay Time L1 0.1ms – 1638.3ms (1 – 16383)
02 Feedback Level L -63 – +63 (1 – 127)
03 Delay Time R1 0.1ms – 1638.3ms (1 – 16383)
04 Feedback Level R -63 – +63 (1 – 127)
05 Feedback High Damp 0.1 – 1.0 (1 – 10)
06 Delay Time L2 0.1ms – 1638.3ms (1 – 16383)
07 Delay Time R2 0.1ms – 1638.3ms (1 – 16383)
08 Delay Level 2 0 – 127 (0 – 127)
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
13 – 16: Same as marked with *.
No. Parameter Range Value Table No.
01 Delay Time L>R 0.1ms – 1638.3ms (1 – 16383)
02 Delay Time R>L 0.1ms – 1638.3ms (1 – 16383)
03 Feedback Level -63 – +63 (1 – 127)
04 Input Select L, R, L&R (0 – 2)
05 Feedback High Damp 0.1 – 1.0 (1 – 10)
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
13 – 16: Same as marked with *.
No. Parameter Range Value Table No.
01 Delay Time 0.1ms – 1486.0ms (1 – 14860)
02 Delay Transition Rate 1 – 48 (1 – 48)
03 Feedback Level -63 – +63 (1 – 127)
04 Feedback High Damp 0.1 – 1.0 (1 – 10)
05 Delay Time Offset 0 – 127 (0 – 127)
06 – 09: Same as marked with *.
10 Dry / Wet Balance D63>W – D=W – D<W63 (1 – 127)
11 Control Type normal, scratch (0 – 1)
28
Data List
*

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
