Yamaha MOTIF ES6 Data List

MIDI PARAMETER CHANGE TABLE (Mode Change)
MIDI PARAMETER CHANGE TABLE (Bulk Control)
MIDI PARAMETER CHANGE TABLE (SYSTEM)
TOTAL SIZE = 60 3C (HEX)
Address Size Data Range
(HEX)
Parameter Name Description Notes
0A 00 00 1 00 – 7F MASTER NUMBER SELECT 0 – 127
01 1 00 – 04 MODE CHANGE 0: Voice,
1: Performance,
2: Pattern (Mix),
3: Song (Mix),
4: Master
Address Size Data Range
(HEX)
Parameter Name Description Notes
0E 00 nn 1 – Bulk Header Normal Voice PRE1 (nn = 0 – 127)
01 nn 1 – Normal Voice PRE2 (nn = 0 – 127)
02 nn 1 – Normal Voice PRE3 (nn = 0 – 127)
03 nn 1 – Normal Voice PRE4 (nn = 0 – 127)
04 nn 1 – Normal Voice PRE5 (nn = 0 – 127)
05 nn 1 – Normal Voice PRE6 (nn = 0 – 127)
06 nn 1 – Normal Voice GM (nn = 0)
08 nn 1 – Normal Voice USER1 (nn = 0 – 127)
09 nn 1 – Normal Voice USER2 (nn = 0 – 127)
0F nn 1 – Normal Voice Edit Buffer (nn = 0)
18 nn 1 – Plug-in Voice PLG1 (nn = 0 – 63)
19 nn 1 – Plug-in Voice PLG2 (nn = 0 – 63)
1A nn 1 – Plug-in Voice PLG3 (nn = 0 – 63)
1F nn 1 – Plug-in Voice Edit Buffer (nn = 0)
20 nn 1 – Drum Voice PRE (nn = 0 – 63)
21 nn 1 – Drum Voice GM (nn = 0)
28 nn 1 – Drum Voice USER (nn = 0 – 31)
29 nn 1 – reserved
2F nn 1 – Drum Voice Edit Buffer (nn = 0)
40 nn 1 – Performance INT (nn = 0 – 127)
41 nn 1 – reserved
4F nn 1 – Performance Edit Buffer (nn = 0)
5F nn 1 – Multi Edit Buffer (nn = 0)
68 nn 1 – reserved
6F nn 1 – reserved
70 nn 1 – Master INT (nn = 0 – 127)
7F nn 1 – Master Edit Buffer (nn = 0)
0F 00 nn 1 – Bulk Footer Normal Voice PRE1 (nn = 0 – 127)
01 nn 1 – Normal Voice PRE2 (nn = 0 – 127)
02 nn 1 – Normal Voice PRE3 (nn = 0 – 127)
03 nn 1 – Normal Voice PRE4 (nn = 0 – 127)
04 nn 1 – Normal Voice PRE5 (nn = 0 – 127)
05 nn 1 – Normal Voice PRE6 (nn = 0 – 127)
06 nn 1 – Normal Voice GM (nn = 0)
08 nn 1 – Normal Voice USER1 (nn = 0 – 127)
09 nn 1 – Normal Voice USER2 (nn = 0 – 127)
0F nn 1 – Normal Voice Edit Buffer (nn = 0)
18 nn 1 – Plug-in Voice PLG1 (nn = 0 – 63)
19 nn 1 – Plug-in Voice PLG2 (nn = 0 – 63)
1A nn 1 – Plug-in Voice PLG3 (nn = 0 – 63)
1F nn 1 – Plug-in Voice Edit Buffer (nn = 0)
20 nn 1 – Drum Voice PRE (nn = 0 – 63)
21 nn 1 – Drum Voice GM (nn = 0)
28 nn 1 – Drum Voice USER (nn = 0 – 31)
29 nn 1 – reserved
2F nn 1 – Drum Voice Edit Buffer (nn = 0)
40 nn 1 – Performance INT (nn = 0 – 127)
41 nn 1 – reserved
4F nn 1 – Performance Edit Buffer (nn = 0)
5F nn 1 – Multi Edit Buffer (nn = 0)
68 nn 1 – reserved
6F nn 1 – reserved
70 nn 1 – Master INT (nn = 0 – 127)
7F nn 1 – Master Edit Buffer (nn = 0)
Address Size Data Range
(HEX)
Parameter Name Description Notes
00 00 00 1 00 – 7F Master Volume 0 – 127 MIDI Master
Volume
01 1 28 – 58 Master Note Shift -24 – +24 [semitones]
02 4 00 – 0F
00 – 0F
00 – 0F
00 – 0F
Master Tune -102.4 – +102.3 [cent]
1st bit3-0 → bit15-12
2nd bit3-0 → bit11-8
3rd bit3-0 → bit7-4
4th bit3-0 → bit3-0
MIDI Master
Tuning
06 1 00 – 01 Controller Reset hold, reset
07 1 35 – 4B Master Transpose -11 – +11 (semitones)
08 1 3D – 43 Master Octave Shift -3 – +3
09 1 00 – 01 Local Switch off, on
0A 1 00 – 10, 7F Basic Receive Channel 1 – 16, omni, off
0B 1 00 – 0F, 7F Keyboard Transmit Channel 1 – 16, off
0C 1 reserved
0D 1 00 – 01 REC ARP Switch off, on
0E 1 00 – 01 STEREO L&R OUTPUT GAIN 00: 0dB, 01: +6dB
0F 1 00 – 01 ASSIGN OUT L&R OUTPUT
GAIN
00: 0dB, 01: +6dB
10 1 00 – 7F INDIVIDUAL OUTPUT GAIN bit0: 0/+6dB 1&2, bit1: 0/
+6dB 3&4, bit2: ... ..., bit6:
0/+6dB 13&14
11 1 00 – 03 BC Curve (for TG) thru, soft, hard, wide
12 1 00 – 04 Keyboard Velocity Curve norm, soft, hard, wide,
fixed
13 1 01 – 7F Keyboard Fixed Velocity 1 – 127
14 1 00 – 01 Receive GM/XG On for Multi
Part PB
off, on
15 1 00 – 01 Receive/Transmit Bank Select off, on
16 1 00 – 01 Receive/Transmit Program
Change
off, on
17 1 00 – 01 MIDI Control Mode mode1, mode2
18 1 00 – 07 Thru Port for USB 1 – 8
19 1 00 – 02 MIDI IN/OUT MIDI, USB, mLAN
1A 1 00 – 07 Effect Bypass for System
Effect
bit0: Reverb,
bit1: Chorus
1B 1 reserved
1C 1 00 – 03 Effect Bypass for Insertion
Effect
bit0: Internal,
bit1: Plug-in Board
1D 1 00 – 01 Auto ROM Demo Song &
Chain Load Switch
off, on
1E 1 00 – 01 AutoLoad Switch off, on
1F 1 00 – 05 Power on Mode Performance, Voice (INT),
Voice (PRE1), GM, last,
Master
20 1 reserved
21 1 00 – 02 Single Part Plug-in Board Port
Assign for Multi Mode
1, 2, 3 Port 1 in any
other mode
22 1 00 – 02 Multi Part Plug-in Board Port
Assign for Multi Mode
1, 2, 3 Port 1 in any
other mode
23 1 00 – 01 Send XG on to Multi Part PB
for Song/Pattern Change
off, on
24 1 reserved
25 1 00 – 01 Analog Input Gain mic, line
26 1 reserved
27 1 00 – 01 Digital Input for AIEB2 coaxial, optical
28 1 00 – 01 Digital Output Word Length
for AIEB2
20bit, 24bit
29 1 00 – 01 mLAN Monitor Switch off, on
2A 1 00 – 55 Assign A Destination off, 1 – 85
2B 1 00 – 55 Assign B Destination off, 1 – 85
2C 1 reserved
2D 1 00 – 5F Assign A Control Number off, 1 – 95
2E 1 00 – 5F Assign B Control Number off, 1 – 95
2F 1 00 – 01 RB Mode hold, reset for Voice Mode
30 1 00 – 5F RB Control Number off, 1 – 95 :
31 1 00 – 65 FS Assign off, 1 – 95, ArpSw, ArpHold,
Play/Stop, PCInc, PCDec,
OctaveReset
32 1 00 – 5F ARP Switch Control Number off,1 – 95
33 1 00 – 5F ARP Hold Control Number off,1 – 95
34 1 00 – 01 ARP MIDI Out Switch off, on for Voice Mode
35 1 00 – 0F ARP MIDI Out Channel 1 – 16 :
36 1 00 – 5F Assign1 Control Number off, 1 – 95 :
37 1 00 – 5F Assign2 Control Number off, 1 – 95 :
38 1 00 – 5F BC Control Number off, 1 – 95 :
39 1 00 – 5F FC2 Control Number off, 1 – 95 :
3A 1 00 – 5F FC1 Control Number off, 1 – 95
3B 1 reserved
Data List
69
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
