Yamaha MOTIF ES6 Data List

TOTAL SIZE = 30 1E (HEX)
TOTAL SIZE = 38 26 (HEX)
MIDI PARAMETER CHANGE TABLE
(NORMAL VOICE ELEMENT)
TOTAL SIZE = 29 1D (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
40 05 00 1 00 – 0C Controller Set1 Source 0:PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
01 2 00
00 – 44
Controller Set1 Destination MSB
Controller Set1 Destination LSB
0 – 68
03 1 00 – 7F Controller Set1 Depth -64 – +63
04 1 reserved
05 1 00 – 0C Controller Set2 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
06 2 00
00 – 44
Controller Set2 Destination MSB
Controller Set2 Destination LSB
0 – 68
08 1 00 – 7F Controller Set2 Depth -64 – +63
09 1 reserved
0A 1 00 – 0C Controller Set3 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
0B 2 00
00 – 44
Controller Set3 Destination MSB
Controller Set3 Destination LSB
0 – 68
0D 1 00 – 7F Controller Set3 Depth -64 – +63
0E 1 reserved
0F 1 00 – 0C Controller Set4 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
10 2 00
00 – 44
Controller Set4 Destination MSB
Controller Set4 Destination LSB
0 – 68
12 1 00 – 7F Controller Set4 Depth -64 – +63
13 1 reserved
14 1 00 – 0C Controller Set5 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
15 2 00
00 – 44
Controller Set5 Destination MSB
Controller Set5 Destination LSB
0 – 68
17 1 00 – 7F Controller Set5 Depth -64 – +63
18 1 reserved
19 1 00 – 0C Controller Set6 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
1A 2 00
00 – 44
Controller Set6 Destination MSB
Controller Set6 Destination LSB
0 – 68
1C 1 00 – 7F Controller Set6 Depth -64 – +63
1D 1 reserved
40 06 00 1 00 – 05 LFO Phase 0, 90, 120, 180, 240, 270
01 1 00 – 0C LFO Wave tri, tri+, sawup, sawdwn,
squ1/4, squ1/3, squ, squ2/3,
squ3/4, trpzd, S/H1, S/H2,
user
02 1 00 – 3F LFO Speed 0 – 63
(available only when the
Tempo Sync is set to off)
03 1 05 – 15 LFO TEMPO SPEED 5 – 21
(available only when the
Tempo Sync is set to on)
16th, 8th/3,
16th., 8th,
4th/3, 8th.,
4th, 2th/3,
4th., 2nd,
Whole/3, 2nd.,
4thX4, 4thX5,
4thX6, 4thX7,
4thX8
04 1 00 – 01 LFO TEMPO SYNC OFF, ON
05 1 00 – 7F LFO Delay Time 0 – 127
06 1 00 – 7F LFO Fade In Time 0 – 127
07 1 00 – 7F LFO Hold Time 0 – 127
08 1 00 – 7F LFO Fade Out Time 0 – 127
09 1 00 – 02 LFO Key On Reset off, each-on, 1st-on
0A 1 00 – 05 LFO Box1 Destination AMD, PMD, FMD, RESO,
PAN, ELEMENT LFO SPEED
0B 1 00 – 7F LFO Box1 Depth 0 – 127
0C 1 reserved
0D 1 00 – 05 LFO Box2 Destination AMD, PMD, FMD, RESO,
PAN, ELEMENT LFO SPEED
0E 1 00 – 7F LFO Box2 Depth 0 – 127
0F 1 reserved
10 1 00 – 05 LFO Box3 Destination AMD, PMD, FMD, RESO,
PAN, ELEMENT LFO SPEED
11 1 00 – 7F LFO Box3 Depth 0 – 127
12 1 reserved
13 1 00 – 06 USER WAVE TOTAL STEP 2, 3, 4, 6, 8, 12, 16
14 1 00 – 03 USER WAVE SLOPE OFF, UP, DOWN, UP&DOWN
15 1 00 – 7F USER WAVE STEP VALUE1 0 – 127
16 1 00 – 7F USER WAVE STEP VALUE2 0 – 127
17 1 00 – 7F USER WAVE STEP VALUE3 0 – 127
18 1 00 – 7F USER WAVE STEP VALUE4 0 – 127
19 1 00 – 7F USER WAVE STEP VALUE5 0 – 127
1A 1 00 – 7F USER WAVE STEP VALUE6 0 – 127
1B 1 00 – 7F USER WAVE STEP VALUE7 0 – 127
1C 1 00 – 7F USER WAVE STEP VALUE8 0 – 127
1D 1 00 – 7F USER WAVE STEP VALUE9 0 – 127
1E 1 00 – 7F USER WAVE STEP VALUE10 0 – 127
1F 1 00 – 7F USER WAVE STEP VALUE11 0 – 127
20 1 00 – 7F USER WAVE STEP VALUE12 0 – 127
21 1 00 – 7F USER WAVE STEP VALUE13 0 – 127
22 1 00 – 7F USER WAVE STEP VALUE14 0 – 127
23 1 00 – 7F USER WAVE STEP VALUE15 0 – 127
24 1 00 – 7F USER WAVE STEP VALUE16 0 – 127
25 1 00 – 7F LFO RANDOM SPEED DEPTH 0 – 127
Address Size Data
Range
(HEX)
Parameter Name Description Notes
41 ee 00 1 00 – 01 ELEMENT ASSIGN 0: OFF, 1: ON
01 1 00 – 01 WAVE SELECT 0: PRESET,
1: USER WAVE,
02 1 reserved
03 2 00 – 7F
00 – 7F
Wave Number MSB
Wave Number LSB
1 – 1859
(User: 1 - 1024)
1st bit6-0 → bit13-7
05 1 reserved
06 1 reserved
07 1 reserved
08 1 01 – 7F Pan L63 – C – R63
09 1 00 – 7F Random Pan Depth 0 – 127
0A 1 00 – 7F Alternate Pan Depth L64 – 0 – R63
0B 1 00 – 7F Scaling Pan Depth -64 – +63
0C 1 00 – 7F Note Limit Low 0 – 127
0D 1 00 – 7F Note Limit High 0 – 127
0E 1 01 – 7F Velocity Limit Low 1 – 127
0F 1 01 – 7F Velocity Limit High 1 – 127
10 1 00 – 7F VELOCITY CROSS FADE 0 – 127
11 1 00 – 7F Key On Delay 0 – 127 (available only when
the Tempo Sync is set to off)
12 1 00 – 01 Key On Delay Tempo Sync 0: OFF, 1: ON
13 1 reserved
14 1 reserved
15 1 reserved
16 1 00 – 02 Insertion Effect Switch thru, insA, insB
17 1 reserved
18 2 00 – 00 CONTROL BOX SW BIT0 – 6: RESERVE
00 – 3F BIT0 – 5: BOX1 – BOX6,
BIT6: RESERVE
1A 2 00 – 00 LFO BOX SW BIT0 – 6: RESERVE
00 – 07 BIT0 – 2: BOX1 – BOX3,
BIT3 – 6: RESERVE
1C 1 05 – 15 Key On Delay Tempo 5 – 21 (available only when
the Tempo Sync is set to on)
16th, 8th/3, 16th., 8th, 4th/3,
8th., 4th, 2th/3, 4th., 2nd,
Whole/3, 2nd., 4thX4, 4thX5,
4thX6, 4thX7, 4thX8
76
Data List
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
