AMX Control Module for: MTX5-D Matrix Processor Rev.1
5
Command/String Index Values
Input Order
1-24 Mono Inputs 1-24
25-28 Stereo Inputs 1L-2R
29-30 SD Card Player
31-34 Effect Return 1L-2R
Input Channel Numbers
1-24 Mono Input Channels 1-24
25-28 Stereo Input Channels 1L-2R
29-30 SD Card Player L/R
31-34 Effect Return 1L-2R
Effect Patches
1 Reverb Hall
2 Reverb Stage
3 Karaoke Echo
4 Vocal Echo
EQ Types
1 Parametric EQ
2 Low Shelf, 6dB/Oct
3 Low Shelf, 12dB/Oct
4 High Shelf 6dB/Oct
5 High Shelf 12dB/Oct
6 HPF (High Pass Filter)
7 LPF (Low Pass Filter)
Audio Source
0 Disconnect
1-8 Analog Mic/Line 1-8
9-12 Analog Stereo In 1L-2R
13-14 SD Card Player
15-30 YDIF 1-16
31-46 Dante 1-16
47-62 Card Slot 1-16
Meter Groups (to Start & Stop)
1 Analog Input Meters (Mic/Line 1-8, St In 1L-2R)
2 Input Channels, Post EQ (Inputs 1-30)
3 Input Channels, Post On (Inputs 1-30)
4 Effect Returns (Effect 1L-2R)
5 Matrix (Zone) Outputs (Zone 1-16)
6 Output Channels (Out 1-16)
Levels on vdvMeters
1-12 Mic/Line 1-8, St In 1L-2R
21-50 Post-EQ meters for Input 1-30
51-80 Post-On meters for Input 1-30
81-84 Post-On meters for Effect Returns 1L-2R
91-106 Post-On meters for Matrix (Zone) Outputs
111-126 Post-On meters for Outputs 1-16
