Yamaha MX200 - Engine Protection for Storage

35
Periodic maintenance
2. Use a flathead screw driver to pry out and remove
the spark arrester from the muffler.
3. Remove the carbon deposits on the spark arrester
using a wire brush.
4. Check the spark arrester.
Replace it if damaged.
5. Install the spark arrester.
TIP
Align the spark arrester lump with the hole in the muf-
fler pipe.
6. Install the screw, and then tighten it.
1
1. Spark arrester
When cleaning, use the wire brush lightly to avoid
damaging or scratching of the spark arrester.
NOTICE
1
2
1. Spark arrester lump
2. Hole
