21
Audio channels
The audio signals of the MX49/MX61 can be output to the USB [TO HOST] terminal and the OUTPUT [L/MONO]/
[R] jacks. When connecting to a computer, use the USB [TO HOST] terminal. In this case, up to two audio
channels (USB 1 and USB2) are available. The audio signals of the MX49/MX61 can be input from the USB [TO
HOST] terminal and the [AUX IN] jack. Up to two channels of audio can be input to the USB [TO HOST] terminal.
Set the output level by setting the “DAW Level” parameter (page 64) on the MX49/MX61. The signals are output to
the OUTPUT [L/MONO]/[R] jack. Also, up to two audio channels can be input to the [AUX IN] jacks. The signal is
sent to directly the OUTPUT [L/MONO]/[R] jack. For more details, see the “MIDI/Audio Signal Flow” section (page
18).
