PARTS LIST
WARNING
Components having special characteristics are marked and must be replaced with parts having
specifi cation equal to those originally installed.
• The numbers “QTY” show quantities for each unit.
• The parts with “--” in “PART NO.” are not available as spare parts.
• This mark “ } ” in the REMARKS column means these parts are interchangeable.
• The second letter of the shaded (
) part number is O, not zero.
• The second letter of the shaded (
) part number is I, not one.
Notes : DESTINATION ABBREVIATIONS
A : Australian model
B : British model
C : Canadian model
D : German model
E : European model
F : French model
H : North European model
I : Indonesian model
J : Japanese model
K : Korean model
M : South African model
O : Chinese model
Q : South-east Asia model
T : Taiwan model
U : U.S.A. model
V : General export model (110V)
W: General export model (220V)
N,X: General export model
Y : Export model
PARTS LIST
CONTENTS
OVERALL ASSEMBLY ..................................................... 2
STAND ASSEMBLY .......................................................... 5
LOWER CASE ASSEMBLY .............................................. 6
KEYBOARD ASSEMBLY .................................................. 8
ELECTRICAL PARTS ............................................... 10–16
DIGITAL KEYBOARD
