RM-WAP-16 RM-WAP-8 Owner’s Manual
Front panel
1 (Power) indicator
2 (Status) indicator
Indicates the status of this unit using a color and flashing pattern. For details, refer to
the Reference Manual.
3 RESET button
Use to reset the settings by long-pressing with a fine-tipped object, then releasing it.
Rear panel
1 UNLOCK switch
Use to remove this unit from the mounting bracket. For details, refer to page 13.
CONTROLS AND FUNCTIONS
Long press Status indicator Reset target
4 seconds to less
than 8 seconds
Flashes blue twice per second
(during long-pressing/resetting)
Network-related settings
8 seconds to less
than 12 seconds
Flashes blue three times per second
(during long-pressing/resetting)
All settings (Automatically
restarts after reset)
1 2 3
1
