RM-WAP-16 RM-WAP-8 Owner’s Manual
Bottom panel
1 Dante/PoE port
This is an RJ-45 port to which you can connect an LAN cable (CAT5e or higher) via an
IEEE802.3af compliant a PoE injector or the PoE network switch to a Dante unit.
For details on injectors, refer to the Reference Manual.
NOTICE : Do not connect this product to a public Wi-Fi and/or Internet service directly. Only
connect this product to the Internet through a router with strong password
protections. Consult your router manufacturer for information on optimum security
practices.
: Do not connect any device here other than a Dante-compatible device or a
device (including a computer) that supports gigabit Ethernet.
2 Mounting cutouts
Use to hook onto the mounting bracket.
3 Cable slots
Use for routing the LAN cable if necessary.
4 Safety wire mounting holes
Use to attach a commercially available safety wire.
5 Heatsinks
Allow internal heat to escape.
NOTICE : Since the heatsinks collect heat, do not directly touch them with your hands. In
addition, avoid direct contact with heat-sensitive objects.
6 Product label
Provides information about this unit and marks of conformity with various standards.
2
5
4
6
2
3
1
