En 1
Check that the following accessories are supplied with the product.
The following cables (not supplied) are required to build the system described in this
document.
• Speaker cables (depending on the number of speakers)
• HDMI cable (x2)
• Audio pin cable (x1)
• Digital optical cable (x1)
(not required if your TV supports ARC [Audio Return Channel])
1 Preparation
Accessories
Remote control Batteries
(AAA, R03, UM-4) (x2)
Insert the batteries the right way round.
AM antenna FM antenna YPAO microphone
Power cable CD-ROM
(Owner’s Manual)
Safety Brochure Easy Setup Guide
• The illustrations of the main unit and remote control used in this guide are of the U.S.A. model, unless
otherwise specified.
*The supplied FM antenna
varies depending on the
region of purchase.
*The supplied power cable
varies depending on the
region of purchase.
Cables required for connections
UAB
This document explains how to set up a 5.1- or 7.1-channel system and
play back surround sound from a BD/DVD on the unit.
To reduce the impact on natural resources, the Owner’s Manual for this product is
supplied on CD-ROM. For more information about this product, refer to the
Owner’s Manual on the supplied CD-ROM.
PDF versions of this guide and “Owner’s Manual” can be downloaded from the
following website.
http://download.yamaha.com/
Easy Setup Guide
English
AV Receiver
