3-11
BIMINI TOP (If Equipped)
Raising from the fully collapsed storage
position.
1) With an assistant, raise the top and
secure the rear support poles to the
rear support pole mounts with the
lock pins.
2) Unzip and remove the storage
cover.
3) Unfold the top by pulling to the bow
of the boat.
NOTE: On the AR210 model, collapse
the front support poles to clear the
wakeboard tower as you pull the top
forward. Extend the poles again until
the bottom sections lock into their fully
extended position.
4) Attach the snap hooks to the strap
eyes.
5) The top should be snug and wrinkle
free. If the top is too loose or too
tight, adjust the front straps by slid-
ing the buckle up or down the strap
as needed.
Do not exceed 45 mph (72 km/h) with
the Bimini top in the up position.
