5-35
5
ECB00091
Never turn an adjusting mechanism be-
yond the minimum and maximum settings.
Adjust the spring preload as follows.
1. Elevate the vehicle and place a suitable
stand under the frame.
2. Loosen the locknut.
3. Turn the spring preload adjusting nut in
direction (a) to increase the spring pre-
load and thereby harden the suspension,
and in direction (b) to decrease the spring
preload and thereby soften the suspen-
sion.
A special wrench can be obtained at a
Yamaha dealer to make this adjustment.
The spring preload setting is determined by
measuring distance A, shown in the illustra-
tion. The shorter distance A is, the higher
the spring preload; the longer distance A is,
the lower the spring preload.
1. Locknut
2. Spring preload adjusting nut
3. Special wrench
111
22
33
(b)(b)
(a)(a)
(b)
(a)
