DESCRIPTION
EC100000
GENERAL INFORMATION
EC110000
DESCRIPTION
1 Clutch lever
2 Hot starter lever
3 “ENGINE STOP” button
4 Trip meter
5 Main switch
6 Start switch
7 Front brake lever
8 Throttle grip
9 Radiator cap
0 Fuel tank cap
A Taillight
B Kickstarter
C Fuel tank
D Headlight
E Radiator
F Coolant drain bolt
G Rear brake pedal
H Valve joint
I Fuel cock
J Cold starter knob
K Air cleaner
L Drive chain
M Shift pedal
N Oil dipstick
O Front fork
NOTE:
●
The machine you have purchased may differ
slightly from those shown in the following.
●
Designs and specifications are subject to
change without notice.
A
BC
D
E
FG
1
2
3
4
5
6
7
8
9
0
HI
J
K
LM
N
O
