PERIODIC MAINTENANCE AND ADJUSTMENT
7-32
7
EAU42452
Replacing a rear turn signal
light bulb
1. Remove the turn signal lens by re-
moving the screws.
2. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screws. NOTICE: Do not over-
tighten the screws, otherwise
the lens may break.
[ECA10681]
EAU24324
Replacing a license plate light
bulb
1. Remove the license plate light unit
by removing the nuts, washers and
rubber dampers.
2. Remove the license plate light lens
by removing the nuts and washers.
1. Screw
1. Turn signal light lens
2. Turn signal light bulb
2
1
1. Nut
2. Washer
3. Rubber damper
123 123
U26S13E0.book Page 32 Tuesday, May 17, 2011 10:56 AM
