SPEC
MAINTENANCE SPECIFICATIONS
ELECTRICAL
Item Standard Limit
C.D.I.:
Magneto model/manufacturer F4T259/MITSUBISHI ----
Pickup coil resistance/color 189 ~ 231 Ω at 20 °C (68 °F)/
White/Green – White/Red
----
Rotor rotation direction detection coil resis-
tance/color
0.065 ~ 0.080 Ω at 20 °C (68 °F)/
Red – White/Blue
----
C.D.I. unit model/manufacturer F8T38683/MITSUBISHI ----
Electric starter system:
Type Constant mesh type ----
Starter motor:
Model/manufacturer 5XG/MORIC TAIWAN ----
Output 0.4 kW ----
Armature coil resistance 0.0144 ~ 0.0176 Ω at 20 °C
(68 °F)
----
Brush overall length 10 mm (0.4 in) 3.5 mm
(0.14 in)
Spring force 563 ~ 844 g (5.52 ~ 8.28 N) ----
Commutator diameter 22 mm (0.87 in) 21 mm
(0.83 in)
Mica undercut 1.5 mm (0.059 in) ----
Starter relay:
Model/manufacturer MS5F-721/JIDECO ----
Amperage rating 180 A ----
Coil winding resistance/color 4.2 ~ 4.6 Ω at 20 °C (68 °F)/
Blue/Black – Blue/White
----
