9 - 33
– +
ELEC
SIGNAL SYSTEM
EB806010
TROUBLESHOOTING
Procedure
Check:
1.Fuses (main, four-wheel drive, ignition, signaling system)
2.Battery
3.Main switch
4.Wiring connections
(the entire signal system)
IF THE BRAKE LIGHT AND/OR AN INDICATOR LIGHT FAILS TO COME ON:
IF THE HORN FAILS TO SOUND (FOR EUROPE AND OCEANIA):
OTE:
●
Remove the following part(s) before
troubleshooting:
1)Seat
2)Fuel tank
3)Air filter case
4)Front carrier
5)Front fender panel
●
Use the following special tool(s) for
troubleshooting.
Pocket tester:
P/N. YU-03112-C, 90890-03112
EB802011
CONTINUITY
1.Fuses (main, four-wheel drive, ignition,
signaling system)
Refer to “CHECKING THE SWITCHES”.
NO CONTINUITY
Replace the fuse.
EB802012
CORRECT
2.Battery
●
Check the battery condition.
Refer to “CHECKING THE BATTERY” in
CHAPTER 3.
Open-circuit voltage:
12.8 V or more at 20 °C (68 °F)
*
INCORRECT
●
Clean the battery terminals.
●
Recharge or replace the battery.
To Next Page
