Indicator lights and warning lights
EBU35450
Neutral indicator light “N”
This indicator light comes on when the trans-
mission is in the neutral position.
EBU35460
Reverse indicator light “R”
This indicator light comes on when the trans-
mission is in the reverse position.
1. Shift timing indicator light
2. Electric Power Steering warning light “EPS”
3. Differential gear lock indicator light “DIFF LOCK”
4. Parking brake indicator light “(P)”
5. Reverse indicator light “R”
6. Neutral indicator light “N”
7. Engine trouble warning light “ ”
8. High beam indicator light “ ”
9. Half clutch indicator light “ ”
10.Launch system indicator light “ ”
11.YCC-S system warning light “ ”
12.Coolant temperature warning light “ ”
13.Drivetrain icon “ / ”
1 2 3 4 5 6 7 8 9
10
11
12
13
1. Helmet indicator light “ ”
2. Seat belt indicator light “ ”
