Yamaha YZF-R6(V) 2006 User Manual

EAS20100
SYMBOLS
The following symbols are used in this manual
for easier understanding.
NOTE:
The following symbols are not relevant to every
vehicle.
G
M
E
B
LS
M
91011
12 13 14
15 16
LT
New
T
R
.
.
123
456
78
1. Serviceable with engine mounted
2. Filling fluid
3. Lubricant
4. Special tool
5. Tightening torque
6. Wear limit, clearance
7. Engine speed
8. Electrical data
9. Engine oil
10.Gear oil
11. Molybdenum disulfide oil
12.Wheel bearing grease
13. Lithium-soap-based grease
14. Molybdenum disulfide grease
15.Apply locking agent (LOCTITE
®
).
16. Replace the part with a new one.

Yamaha YZF-R6(V) 2006 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, forward-inclined parallel 4-cylinder
Displacement	599 cc
Bore x Stroke	67.0 x 42.5 mm
Compression Ratio	12.8 : 1
Fuel System	Fuel injection
Lubrication system	Wet sump
Final Drive	Chain
Rear Suspension	Swingarm, (link suspension)
Front Tyre	120/70 ZR17M/C (58W)
Rear Tyre	180/55 ZR17M/C (73W)
Overall Length	2, 040 mm
Overall Height	1, 100 mm
Seat Height	850 mm
Minimum Ground Clearance	130 mm
Oil capacity	3.4 litres
Ignition	TCI
Clutch Type	Wet, multiple-disc
Transmission	6-speed
Frame type	Aluminium Deltabox
Front Brake	Dual 310 mm discs
Rear Brake	220 mm disc
Fuel Capacity	17 liters
