8 - 34
–+
ELEC
ELECTRICAL CONTROL SYSTEM
Operation after entering the diagnosis
mode
• Select a diagnosis code by holding down
the MODE switch while pressing either
the UP or DOWN switch. Refer to the diag-
nosis code list.
First, press the UP switch once to select
diagnosis code 01 or press the DOWN
switch once to select diagnosis code 31.
Afterwards, each press of the UP switch
or the DOWN switch respectively
increases or decreases the diagnosis code
number by one. If diagnosis code 00 is
selected, pressing the DOWN switch once
selects diagnosis code 31. If diagnosis
code 31 is selected, pressing the UP
switch once selects diagnosis code 00.
• Release the MODE switch to start the test
for the selected diagnosis code.
NOTE:
To select another diagnosis code, hold
down the MODE switch and press either the
UP switch or the DOWN switch.
Example:
First, select diagnosis code 29 in either of
the following ways.
• Hold down the MODE switch, press the
UP switch 29 times, and then release the
MODE switch.
• Hold down the MODE switch, press the
DOWN switch 3 times, and then release
the MODE switch.
Next, select diagnosis code 10 in either of
the following ways.
• Hold down the MODE switch, press the
UP switch 13 times, and then release the
MODE switch.
• Hold down the MODE switch, press the
DOWN switch 19 times, and then release
the MODE switch.

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
