EAU1722A
PERIODIC MAINTENANCE AND ADJUSTMENT
6-28
Tail/brake light<IXE>
Turn signal light bulb, replacing<IXE>
EAU43040
Tail/brake light
1
1. Tail/brake light
If the tail/brake light does not come on,
have a Yamaha dealer check its electri-
cal circuit or replace the bulb.
EAU24204
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screw.
1
1. Turn signal light Bulb
1
1. Turn signal light Bulb
2. Remove the burnt-out bulb by push-
ing it in and turning it counterclock-
wise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw.
NOTICE:
Do not over-
tighten the screw, otherwise the
lens may break.[ECA11191]
