YL110/210 Third Function Valve Kit for SA Tractors
YL110/210 Third Function Valve Kit
2. Kit Contents
Your YL110/210 Third Function Valve Kit comes complete with all the parts needed. Before assembling and
installing the Third Function Valve Kit, take inventory and check to be sure all the parts listed in the parts list and
shown in the illustrations below are in the kit.
If you should find any parts missing, contact your YANMAR dealer to obtain the missing parts. Do not install the
Third Function Valve Kit to the loader or tractor with after market parts, incorrect parts or missing parts. Possible
injury or damage to the machine may result.
The images in the manual represent the YL110 Third Function Valve Kit. There are only minor differences
between YL110 and YL210 Third Function Valve Kits. The same instructions apply for YL110 and YL210 with
regards to assembly and installation.
Item No.
YL110
Part Number
YL210
Part Number
Part Description Qty.
1 1A7880-47570 1A7880-47570 Yellow Dust Plug 1
2 1A7880-47580 1A7880-47580 Green Dust Plug 1
3 198223-46250 198223-46250 Hydraulic Quick Coupler 2
4 1TN339-43050 1TN339-43050 Coupler Stay 1
5 22242-000220 22242-000220 Snap Ring (22) 2
6 1TN323-43110 1TN323-43110 Valve Assembly 1
7 1TN328-43410 1TN329-43410 Valve Stay Plate 1
8 26106-080902 26106-080902 M8x100 Bolt 4
9 22117-080000 22117-080000 8 Washer 4
10 26366-080002 26366-080002 8 U-nut 4
11 1TN328-43420 1TN329-43420 Valve Back Plate 1
12 1A7882-47210 1A7882-47210 Joint Assembly 6
13 1TN328-43320 1TN328-43320 Extension Harness 1
14 1TN328-43040 1TN328-43040 C Hose—Straight swivel fitting & short 90° elbow 2
15 1A8300-51210 1A8300-51210 Repeat Band 10
16 1TN328-43050 1TN329-43050 D Hose—Straight fittings on both ends 2
17 1TN328-43190 1TN329-43190 B Hose—Straight fitting and short 90° elbow 1
18 1TN328-43180 1TN329-43180 A Hose—Straight fitting and long 90° elbow 1
19 1TN328-43030 1TN328-43030 Pipe Band 4
20 1TN328-43520 1TN328-43520 M6x35 Iso4017 Bolt 2
21 1TN328-43450 1TN328-43450 Lock Regen Plate 1
22 1TN328-43250 1TN328-43250 F Sleeve Handle 1
23 1TN328-43550 1TN328-43550 M6x8 Set Screw 2
24 172663-17950 172663-17950 Vessel Knob Assembly 1
25 1TN328-43540 1TN328-43540 M4x6 Set Screw 1
26 1TN328-43530 1TN328-43530 M4 ISO7089 Washer 2
27
1TN328-43310 1TN328-43310 Electrical Harness 1
28 29622-250001 29622-250001 250 Band 10
29 129927-91151 129927-91151 Diode Harness 1
30 119247-77100 119247-77100 Power Relay 1
31 1TN328-43500 1TN328-43500 Hose Cover M Assembly 1
32 0F052-EN0050 0F052-EN0050 Assembly Instructions 1
