YL110/210 Third Function Valve Kit for SA Tractors
YL110/210 Third Function Valve Kit
4. Tractor Connection
1. Attach the D Hoses (16) to the matching tractor
mounted quick couplers.
2. Connect the Electrical Harness End (27a) to the
Extension Harness (13).
3. When fully connected, make sure all hoses and
electrical wiring is secured to the tractor and
loader. Make sure all Repeat Bands are tightened
and trimmed.
4. To pressurize the hydraulic system after
connection, press and hold the Third Function
Button (S) while slowly moving the control lever to
the left and right.
5. Move the control lever to the right and left without
holding the Third Function Button.
1. Park the tractor and loader in a level and stable
area that is illuminated.
2. Disconnect electrical harness.
3. Refer to the Loader Operator’s Manual for proper
safety practices and disconnection procedure.
4.1 Connect to the Tractor
Port D (yellow)
Port A (green)
16
13
27a
4.2 Disconnect from the Tractor
S
