YL110/210 Third Function Valve Kit for SA Tractors
YL110/210 Third Function Valve Kit
7. Connect the Electrical Wiring Harness (27d)
connector to the rear external connector (R)
located at the rear of the tractor.
8. Electrical Wiring Harness connector (27e)
becomes the default external connector.
9. Secure all wires and cover any open connectors.
Parts needed
:
1. Remove the two Bolts (8) that secure the Valve
Assembly to the loader.
2. Secure the Hose Cover (29) and Valve Assembly
to the loader with the two Bolts removed earlier.
27d
R
27e
3.8 Installing Hose Cover
Item
No.
Part No. Description Qty.
31 1TN328-43500 Hose Cover 1
Tightening Torque:
17–22 ft-lb (23–29 Nm)
8
31
