YARD Commander YTL31105 User Manual

- 17 -
BRUSH REPLACEMENT
1. Remove the hopper bag from lawn sweeper.
2. Only replace one brush at a time.
3. Tip the sweeper forward on housing. Do not remove the hex bolts from double brush retainers.
4. Loosen hex bolts and hex lock nuts from single brush retainers. Slide brush out of retainers,
making note of over-lap bristles position.
5. Install new brush, make sure the over-lap bristles are in the positioned as before
IMPORTANT:
If a part needs replacement, only use parts that meet the manufacturer’s specifications. Replacement
parts that do not meet specifications may result in a safety hazard or poor operations.
WARNING
Before storing the sweeper always empty the hopper bag to avoid spontaneous combustion.
STORAGE
 Empty hopper bag before storing the sweeper.
 Clean the sweeper and hopper thoroughly to help prevent rust and mildew.
 Before storing make sure the sweeper is clean and dry for years of trouble free service.
 Collapse the hopper bag for storage, remove the two support rods from the rear of the hopper.
 Lightly lubricate all sweeper surfaces and moving parts to prevent rust.
 Store indoors or protected area during severe weather and winter months.

YARD Commander YTL31105 Specifications

General

Brand	YARD Commander
Model	YTL31105
Category	Lawn Sweeper
Language	English
