Yard-Man 53AA1A3G401 - Page 23

23
Model 53AA1A3G401
REF.
NO.
PART
NO. DESCRIPTION
1. 731-3326 Engine Cover
2. 731-3263 Control Handle
3. 710-0451 Carriage Bolt 5/16-18 x .750
4. 735-0251 Foot Pad
5. 731-3185 Bellow
6. 712-0431 Flange Lock Nut 3/8-16
7. 703-2807B Mounting Bracket
8. 710-3168 Carriage Bolt 3/8-16
9. 749-3081 Cruise Control Handle
10. 731-3128A Lens
11. 710-0642 Hex Washer Screw 1/4-20 x .750
12. 703-2648 Bellow Retainer Bracket
13. 738-0754 Shoulder Screw .437 x .54
14. 731-3325 Seat Base
15. 703-3288 Cruise Control Mounting Bracket
16. 712-3004A Flange Lock Nut 5/16-18
17. 710-0276 Carriage Screw 5/16-18 x 1.0
18. 736-0242 Bell Washer .340 ID x .872 OD
19. 720-0241 Wing Nut Knob 5/16-18
20. 726-0289 Plug
21. 731-3329 Console
22. 738-3163A Shoulder Screw .75 x .245 3/8-16
23. 736-3039 Flat Washer .406 x 1.5
24. 703-2928 Body Hinge
25. 710-0376 Hex Cap Screw 5/16-18 x 1.0
26. 736-0226 Flat Washer .474 ID x .879 OD
27. 738-0296 Shoulder Screw .437 x .286
28. 712-0185 Speed U-Type Nut 1/4-20
29. 732-0830 Spring Clip
30. 720-0302 Lever
31. 731-3195A Control Panel LH
32. 726-3047 Push Nut
33. 603-0424 Control Panel Asm LH
34. 723-3042 Snap Bushing
35. 712-0453 Retainer Nut 1/4-20
36. 747-3303 Support Rod
37. 726-0106 Speed Cap 1/4
38. 710-3015 Hex Cap Screw 1/4-20 x .75
39. 603-0643 Spring Clip Bracket Asm
40. 712-3027 Hex Flange Nut 1/4-20
41. 749-3082 Engine Support Tube
42. 710-3180 Hex Cap Screw 5/19-18 x 1.75
43. 750-3200 Spacer
44. 710-0946 Machine Screw 1/4-20 x .625
45. 731-3327 Body
46. 725-3233 Electric PTO Knob
47. 703-1341B Key
48. 603-0425 Control Panel Asm RH
49. 731-3196 Control Panel Cover RH
50. 603-0578 Body Mounting Plate Asm
51. 731-3328 Front Body Floor
52. 703-3078 Support Latch Bracket
