Yard-Man 53AA1A3G401 - Page 37

37
Model 53AA1A3G401
REF.
NO.
PART
NO. DESCRIPTION
1. 757-3014 Seat
2. 731-3154 Seat Slide
3. 712-3004A Flange Lock Nut 5/16-18
4. 732-3098 Spring Index
5. 720-0190 Height Adjustment Knob
6. 603-0294 Seat Base Bracket Assembly
7. 712-3005 Flange Lock Nut 3/8-16
8. 732-3080 Spring Compression
9. 738-0372 Shoulder Spacer
10. 710-1260A Hex Washer Screw 5/16-18 x .750
11. 747-3342 Rod
12. 710-0520 Hex Cap Screw 3/8-16 x 1.5
13. 710-0347 Hex Cap Screw 3/8-16 x 1.75
14. 736-0227 Flat Washer .390 ID x 1.5 OD
15. 603-0318A Seat Spring Plate Assembly
16. 738-3156 Shoulder Spacer
17. 738-0296 Shoulder Screw
18. 714-0104 Cotter Pin
19. 732-0827 Torsion Spring 5/16
20. 736-0314 Thrust Washer
21. 738-3166 Shoulder Spacer
22. 603-0470 Seat Mounting Bracket Assembly
