Yard-Man 53AA1A3G401 - Page 43

43
Model 53AA1A3G401
REF.
NO.
PART
NO. DESCRIPTION
1. 732-0556 Spring Extension .94 OD x 7.57 LG
2. 712-3006 Hex Nut 1/4-20
3. 710-0597 Hex Cap Screw 1/4-20 x 1.0
4. 703-2559 Stop Bracket
5. 703-2945 Pulley Shield LH
6. 703-3237 Pulley Shield RH
7. 712-3004A Flange Lock Nut 5/16-18
8. 737-3000 Grease Fitting 3/16
9. 603-0580 Rod Assembly
10. 710-1336 Spindle Bolt 3/4-16 x 4.25
11. 756-3089 Pulley
12. 738-0213 Shoulder Screw
13. 736-0192 Flat Washer .531 ID x .93 OD
14. 732-0851A Extension Spring .75 OD x 8.63 LG
15. 750-0151 Spacer .550 ID x .750 OD
16. 603-0316 Deck Assembly 42”
17. 711-3358 Pin Roller
18. 712-0431 Lock Flange Nut 3/8-16
19. 710-3151 Hex Cap Screw 5/8-18 x 4.25
20. 736-0258 Flat Washer .385 ID x 1.0 OD
21. 736-0290 Flat Washer 5/8 ID x 1.0 OD
22. 741-0524 Bearing .625 ID x 1.57 OD
23. 716-3020 Snap Ring
24. 756-0627 Flat Idler Pulley
25. 756-3103 Double Pulley
26. 712-0239 Hex Lock Nut 1/2-20
27. 736-0179 Flat Washer 1/2 ID x 1.25 OD
28. 736-0188 Flat Washer .76 ID x 1.49 OD
29. 750-0656 Spacer .50 OD x .75 ID
30. 741-0338 Flange Bearing 3/4 ID x .52 LG
31. 603-0581 Pivot Arm Pulley Asm
32. 732-0850 Spring Extension 1.0 OD x 6.14 LG
33. 736-0100 Flat Washer .531 ID x 1.25 OD
34. 603-0584 Deck Mounting Plate Asm
35. 736-0187 Flat Washer .64 ID x 1.24 OD
36. 710-3037 Hex Cap Screw 3/8-16 x 1.75
37. 738-0988 Shoulder Spacer
38. 750-3164 Spacer .635 ID x 2.0 LG
39. 703-3147 Idler Pivot Arm
40. 754-3092 V-Belt
41. 731-3005 Roller
42. 710-1260A Hex Washer Screw 5/16-18 x .750
43. 742-3033 Blade
44. 712-3078 Hex Flange Nut 3/4-16
45. 748-3065 Spindle Spacer
46. 710-3178 Carriage Bolt 3/8-16 x .75 LG
47. 714-0115 Cotter Pin
48. 747-3013 Support Pin
49. 715-3003 Pin
50. 732-0802 Spring Compression
51. 736-0160 Flat Washer .536 ID x .930 OD
52. 731-1032 Chute Asm
53. 710-0751 Hex Cap Screw 1/4-20 x .620
54. 736-0270 Bell Washer .265 ID x .75 OD
55. 618-3129 Spindle Assembly
56. 711-3314 Roller Pin
57. 710-3008 Hex Cap Screw 5/16-18 x .75
