Yard-Man YM25 - Page 67

E23
PARTS LIST
14
15
12
16
1
7
8
10
13
5
4
3
2
Item Part No. Description
1 791-00057 Throttle Housing and Trigger Assembly
(includes 2 & 3)
2 791-182690 Throttle Trigger Spring
3 791-00058 Throttle Trigger
4 791-182877 Throttle Cable Assembly
5 753-04236 Upper Drive Shaft Housing Assembly
6 791-610327 Harness Clip
7 791-180809 Deluxe D-Handle Assembly (includes 8-10)
8 791-181070 Screw
9 791-182167 Deluxe D-Handle
10 791-182168 Bottom Clamp
11 753-1190 EZ-Link Coupler (includes 11-15)
12 791-182057 Screw
13 791-181617 Bolt
14 791-181618 Adjustment Knob (includes 11)
15 791-181886 Knob Retaining Nut
16 791-180340 Lower Drive Shaft Housing Assembly
17 791-153597 Lower Clamp Assembly
18 791-181852 Lower Flexible Drive Shaft
19 791-180531 Shield Mounting Screw
20 791-181857 Bushing Housing Assembly
21 791-145569 Anti-Rotation Screw
22 791-181659 Shield and Blade Assembly (includes 23)
23 791-181823 Blade Assembly
24 791-181457 Outer Spool and Eyelet Assembly w/ Retainer
25 791-181458 Retainer
26 791-181561 Thrust Washer
27 791-181459 Small Spring
28 791-181461 Slider
29 791-181532 E-Clip
30 791-181531 Spring
31 791-181462 Plunger
32 791-181463 C-Clip
33 791-181464 Inner Reel
34 791-181465 Large Spring
35 791-181467 Foam Seal
36 791-181468 Bump Head Knob Assembly (includes 34 & 35)
37 791-182405 Switch Assembly
Optional Accessories
* 791-181460 Reel and Line Assembly
* 791-682075 Shoulder Strap Assembly
* Items Not Shown
20
18
19
23
28
26
29
30
25
27
21
22
24
34
32
31
36
33
35
37
17
9
6
1
38
BOOM AND TRIMMER PARTS - MODEL YM25
2-CYCLE GAS TRIMMER
PPN 41ADY25C401
