Yard-Man YM26CO - Page 99

E35
YM26CS PARTS LIST
1
16
17
14
18
19
6
7
8
9
11
10
12
13
15
5
4
3
2
22
20
24
21
29
27
30
31
26
28
23
13
25
35
33
32
37
34
36
38
Item Part
No. Description
1 753-04294 Throttle Housing Assembly (includes 2 & 3)
2 791-610314 Throttle Trigger Spring
3 753-04295 Throttle Trigger
4 753-1231 Throttle Cable Assembly
5 753-1247 Upper Drive Shaft Housing Assembly
6 791-180687 J-Handle Assembly
7 791-683295 Handle Bracket Assembly (includes 8-13)
8 791-181811 Screw
9 791-181812 Upper Handle Clamp
10 791-181813 Middle Handle Clamp
11 791-181814 Lower Handle Clamp
12 791-181815 Nut
13 791-145569 Anti-Rotation Screw
14 791-182928 Split Boom Coupler (includes 15-18)
15 791-182057 Screw
16 791-181617 Bolt
17 791-181618B Adjustment Knob (includes 18)
18 753-04386 Knob Retaining Nut
19 791-182387 Lower Drive Shaft Housing Assembly
(includes 21)
20 791-153597 Lower Clamp Assembly (includes 13)
21 791-181852 Lower Flexible Drive Shaft
22 791-180531 Shield Mounting Screw
23 791-181857 Bushing Housing Assembly
24 791-683274 Shield Assembly (includes 25)
25 791-682061 Blade Assembly
26 791-181457 Outer Spool Assembly (includes 27)
27 791-181458 Retainer
28 791-181561 Thrust Washer
29 791-181459 Small Spring
30 753-04257 Slider
31 791-181532 E-Clip
32 791-181531 Spring
33 791-181462 Plunger
34 791-181463 C-Clip
35 791-181464 Inner Reel
36 791-181465B Large Spring
37 791-181467 Foam Seal
38 791-181468B Bump Head Knob Assembly (includes 36 & 37)
Optional Accessories
* 791-181472 Replacement Line, 0.080 Diameter
(Eight - 10 ft lengths)
* 791-181460B Reel and Line Assembly
* 791-682075B Shoulder Strap Assembly
* Items Not Shown
BOOM AND TRIMMER PARTS - MODEL YM26CS
4-CYCLE GAS TRIMMER
