ATTACHING SWEEPER HITCH TO TRACTOR
(Figures 20, 21, 22)
1. Place the tractor and sweeper on a flat level surface.
2. Set the sweeper height adjustment handle to about the middle of its adjustment range.
3. Attach the sweeper hitch brackets to the tractor hitch, arranging the 3/4” spacers so that the bottom
of the sweeper bag is approximately level and 5” to 7” above the ground. See figure 21 for tractor
hitches that are 10” to 13” above the ground. See figure 22 for tractor hitches that are 8” to 10”
above the ground.
IMPORTANT: For best performance, the bottom of the sweeper bag should be approximately level and
5” to 7” off the ground as shown in figure 20.
