Yardbeast YB2090 User Manual

BASE & TOWING KIT
No
C
1
Base
2
Front support
3
Hitch
4
Trailer stand
5
Knob
6
Pneumatic wheel
7
Trailer axle
8
Hitch pin
9
Ring
10
3/8” Lock washer
11
3/8” x 1”Hex bolt
12
3/8” x 1
13
3/8” Hex nut
14
Cotter pin
15
¾” Slotted nut
16
¾”Flat washer
C
omponent Part No.
Base
2090201
Front support
2090202
Hitch
2090203
Trailer stand
2090204
Knob
2090205
Pneumatic wheel
2090206
Trailer axle
2090207
Hitch pin
2090208
Ring
2090209
3/8” Lock washer
2090210
3/8” x 1”Hex bolt
2090211
3/8” x 1
½” Hex bolt
2090212
3/8” Hex nut
2090213
Cotter pin
2090214
¾” Slotted nut
2090215
¾”Flat washer
2090216
23
