26
3" (7,6 cm)
x1
3" (7,6 cm)
x12
2" (5,1 cm)
x27
PARTS REQUIRED:
LEFT SIDE WALL INSTALLATION
1-1/2" (3,8 cm)
x11
(3,8 cm)
Nails
6" (15,2 cm)
Secure wall with (1) 2" screw through
left wall panel into back wall bottom
and top plates .
Secure wall to bottom plate fi rst.
Secure lower edge of panels to oor
with 2" nails spaced 6" apart.
Angle nails into oor frame .
Secure side wall bottom plates
to oor with 3" nails .
Secure top plates with (1) 3" screw
angled at the corner .
ENSURE PANEL CORNERS ARE FLUSH.
1
2
3
4
Flush
Screw
Screw
Center left side wall on the oor.
Your left side wall is now installed.
Remove temporary support.
FINISH
Screw
Nails
Nails
Nails
6"
(15,2 cm)
2" (5,1 cm)
x2
To Next Page
