36
Assemble gable unit panels with the primed side facing up.
FRONT GABLE UNIT
PARTS REQUIRED:
1-3/4"
(4,4 cm)
1-3/4"
(4,4 cm)
1-1/2"
(3,8 cm)
Install center gable panel on (2) .
Secure with 1-1/2" nails spaced evenly.
1
2
Install left and right gable panels ush
to installed panel.
Secure with 1-1/2" nails spaced evenly.
Flush Flush
Nails
Nails
1-1/2" (3,8 cm)
x28
x2
2 x 4 x 40-15/16" (5,1 x 10,2 x 86,4 cm)
x1 x1 x1
FlushFlush
FINISH
Your front gable unit is now assembled.
