YARDMAX YB4628 User Manual

AUGER CLUTCH
HANDLEBAR RECOIL STARTER
1. Remove the cable adjuster link from the hole in the auger
clutch handle.
2. Pull the tensioning cable up.
3. Connect tensioning cable with the cable adjuster link.
4. Make sure the cable adjuster link hook the lower hole in the
auger clutch handle.
M8 X 45 X 4
3
2. Install the handle to the lower handle using four M8X45 screws,
washers and nuts. Be sure not to pinch or kink the auger clutch
cable in the process.
1. Align the holes in the handlebars and the holes in the lower
handle. Note Figure 3a below that the handle must face
upward to work properly.
1. Slowly pull the recoil starter handle up towards the eye bolt.
2. Slip the recoil starter rope into the eye bolt from the back of
the snow thrower.
1 2
3 4
Tensioning Cable
Lower Hole
Ends of the Hole
13 mm
Figure 4
Figure 5
10
Single-Stage Snow Blower
»
Operator’s Manual
Assembly
|
Figure 3a
Figure 3b
30230US25M100.indd 10 2016/9/3 11:04:16

YARDMAX YB4628 Specifications

General

Brand	YARDMAX
Model	YB4628
Category	Snow Blower
Language	English
