MAINTENANCE
ENGINE
Refer to the Engine Operator’s Manual.
LUBRICATION
Lubricate the pivot points on the auger clutch lever and the spring
at the end of the clutch cable with a light oil once every season
before off-season storage.
AUGER GEARBOX
Lubricate the pivot points on the auger clutch lever and the spring
at the end of the clutch cable with a light oil once every season
before off-season storage.
OFF-SEASON STORAGE
Refer to the Engine Manual for information on storing
your engine.
At the end of the season or if the Snow thrower will not be used for
30 days longer, follow the storage instructions below.
1. Run the engine until the fuel lines and carburetor are empty
and it stops due to lack of fuel.
2. Remove the safety ignition key and allow the engine to cool.
3. Lubricate the machine as instructed.
4. Clean the exterior of the engine and the snow thrower
thoroughly.
5. Touch up all rusted or chipped paint surfaces; sand affected
areas before painting, and use a rust preventative to prevent
the metal parts from rusting.
6. Tighten all loose screws, bolts, and locknuts. Repair or replace
any damaged parts.
7. Cover the machine and store it in a clean, dry place out of the
reach of children.
SERVICE
AUGER BELT REPLACEMENT
If the auger belt becomes worn, oil-soaked, or otherwise damaged,
proceed as follows to replace the belt.
1. Remove the screws that hold the belt cover in place and set
the cover aside.
2. Remove the bolts, big washer, and lock washer from the auger
pulley.
3. Using large mouth pliers grip the drive pulley to loosen the
bolt.
10 mm
