No. Description QTY.
1 Bearing Cup 2
2 Bolt M8x25 10
3 Rubber Auger 2
4 Bolt M6x25 4
5 Flange Locknut M8 9
6 Auger Shaft 1
7 Bearing6203-2RS 2
8 Bolt M6x16 4
9 Scraper Blade 1
10 Flange Locknut M6 9
11 Bolt M8x25 4
12 Support Plate Left 1
13 Screw M8x16 21
14 Idler Pulley Bracket 1
15 Locknut M6 3
16 Belt 1
17 Auger Big Pulley 1
18 Big Flat Washer 6 1
19 Spring Washer 6 1
20 Bolt M6x20 1
21 Screw M5x12 3
22 Screw M6x40 2
23 Belt cover 1
24 Bolt 5/16 1
25 Big Flat Washer 8 1
26 Drive Pulley 1
27 Bolt M8x55 1
28 Big Washer 8 5
29 Drive Clutch Idler 1
30 Bushing 1
31 Locknut M8 2
32 Screw M6x16 2
33 Bolt M6x35 1
34 Big Washer 6 2
35 Spring 1
36 Cable Roller 1
37 Roller Shaft 1
38 Spring Washer 8 4
No. Description QTY.
39 Roller Bushing 1
40 Key A5x18 1
41 Support Base Plate 1
42 Chute Adapter 1
43 Auger Reinforcing Plate 1
44 Support Plate Right 1
45 Screw ST8x16 7
46 Shroud Assembly 1
47 Screw ST6.3x19 2
48 Retaining Washer 2
49 Lock-up Spring Plate 1
50
Chute Base 1
51 Screw M8x40 4
52 Arc Washer 8 8
53 Locknut M8 8
54 Clutch Cable 1
55 Wheel Cap 2
56 Wheel 2
57 Wheel Bushing 2
58 Wheel Axle 1
59 Circlip 14 2
60 Washer 14 2
61 Screw ST6.3x16 2
62 Key B4x6.5x18 1
63 Shroud Assembly Backplate 1
64 Rubber Plug 1
65 Electric Starter Bracket 1
66 Bolt M6x16 1
67 Adjuster Link 1
68 Spring Cover 1
69 Spring 1
70 Engine 1
71 Upper Handle 1
72 Auger Clutch Handle 1
73 Chute Handle 1
74 Screw ST6.3x25 4
75 Swing Knob 1
76 Chute Deector 1
PARTS LIST
21
|
Parts List
