The gearbox was lled with lubricant to the proper level at the
factory. Unless there is evidence of leakage or service has been
performed on the gearbox, no additional lubricant should be
required. If lubricant is required, use GL-5 or GL-6, SAE85-95, EP
gear oil lubricant. Do not use synthetic oil.
Lightly lubricate all moving parts of the machine at the end of the
season or every 25 operating hours.
AUGER GEARBOX
GENARAL LUBRICATION
ENGINE
LUBRICATION
MAINTENANCE
Refer to the Engine Operator’s Manual.
When lubricating auger shaft, remove shear pins
to apply oil inside the shaft and around spacers and
ange bearings found at either end of the shaft.
Remove the wheels to apply grease the wheel shaft.
Do not allow grease or oil get on friction disc, friction
plate or belts. Do not excessively oil the machine;
extra oil may enter the traction drive and cause the
traction drive belt to slip.
Oil
Grease
19
|
Maintenance
