PARTS LIST
PARTS LIST
No. Description Qty
1 Oil Seal M10x1 1
2 Spiral Assembly-Right 1
3 FT Bolt M6x20 8
4
Spring Washer 6 15
5 Flat Washer 6 10
6 Seal B20x35x7 2
7 Screw M5x10 1
8 Auger Gearcase Housing-Right 1
9 Auger Shaft 1
10 Clevis Pin 1.8 5
11 Worm Wheel 1
12 Shaft Sleeve 2
13 Auger Gearcase Housing-Left 1
14 Washer 2
15 Spiral Assembly-Left 1
16 Bearing Box 2
17 Screw ST8x16 6
18 Big Washer 2
19 Shear Pin 2
20 Half Round Key 5x7.5x19 1
21
Ball Bearing 6001-2RS 1
22 Roll Pin 6x37 2
23 Impeller Shaft 1
24 Washer 1
25 Seal B20x35x7 1
26 Ball Bearing 61904-2RS 1
27 Thrust Bearing 51104 1
28 Impeller Assembly 1
29 Bolt M8x16 5
30 Flat Washer 8 5
31 Shave Plate 1
32 Lock Nut M8 9
33 Bolt M8x20 5
34 Skid Shoe (Metal) 2
35 Hex. Flange Nut M8 9
36 Bolt M8x25 2
No. Description Qty
37 Plug 5
38 Auger Housing Assy. 1
39 Screw ST5.5x13 3
40 Chute Clean-Out Tool 1
41 Clean-Out Tool Mounting Bracket 1
42 Chute Crank Flange 1
43 Discharge Chute 1
44 FT Bolt M6x30 6
45 Chute Flange Keeper 3
46 Flange Lock Nut M6 12
47 Screw M5x6 2
48 Discharge Chute Washer 1
49 Ball Bearing 60203-2RS 1
50 Bearing Housing 1
51 Auger Pulley 1
52 Big Flat Washer 8 2
53 Auger Belt 4LXP960 1
54 Spring Washer 8 3
55 Bolt M8x25 1
56 Chute Crank Bracket 1
57 Bushing 1
58 Flat Washer 6 8
59 FT Bolt M6x20 2
60 Handle Knob Assembly 1
61 Lock Washer 2
62 Bolt M8x35 1
63 Bolt M8x20 1
64 Chute Linkage Plate 1
65 Wheel 1
66 Flat Washer 8 5
67 Auger Idler 1
68 Spacer 1
69 FT Bolt M8x35 1
70 Pivot Bolt 1
71 Screw M8x16 12
72 Auger Idler Bracket 1
No. Description Qty
73 Extension Spring 1
74 Auger Idler Mounting Bracket 1
75 Friction Wheel Cable 1
76 Big Gear 1
77 Pin A6x35 1
78 Frame Cover 1
79 Gearbox Main Frame 1
80 Wheel Shaft 1
81 Shaft Bushing 2
82 Shaft Spacer 2
83 Wahser 3
84 Lock Pin 8 2
85 Wheel 1
86 Pin 6x36 2
87 Auger Cable Holder 1 1
88 Shift Arm 1
89 FT Bolt M6x10 8
90 Friction Wheel Side Plate 2
91 Rubber Ring 1
92 Snap Ring 15 2
93 Ball Bearing 60203-2RSN 2
94 Friction Wheel Hub 1
95 Clevis Pin 2 1
96 Nut M6 3
97
FT Bolt M6x25 4
98 Bolt M6x30 1
99 Lock Nut M6 3
100 Screw M6x16 10
101 Fork Bracket 1
102 Fork Assembly 1
103 Circlip 35 1
104
Hex Shaft 1
105 Circlip 40 2
106 Auger Cable Holder 2 1
107 Cable Roller 3
108 Roller Bushing 3
