PARTS LIST
No. Description
Qty
38 Shaft 2 1
39 Wear-Resisting Gasket 5 2
40 Flat Washer 12 30
41 Spring Washer 10 30
42 Nut M10 6
43 Flange Lock Nut M6 6
44 Bushing 2
45 O-Ring 73×2.65 2
46 Oil Seal FB-25×40×8 2
47 Pressure Washer 2
48 Spring Washer 6 6
49 Screw M6×16 6
50 Gear 1 2
51 Spacer 1
52 Gear 2 1
53 Tine Shaft 1
54 Wear-Resisting Gasket 2 1
55 Wear-Resisting Gasket 4 1
56 Gear 3 1
57 Chain 1
58 Gear 3A 1
59 Chain 10A-50 1
60 Screw M6×12 23
61 Bolt M6×16 1
62 Oil Seal FB-20×35×8 2
63 Engine Shaft Washer 2
64 Lock Nut M10 1
65 Counterweight 2 1
66 Gear Cover Mount Bracket 2
67 Clip 1.8 4
68 Right Wheel Assy 1
69 Pin Shaft B8×45 2
70 Flat Washer 10 3
71 Direction Indicator Weldment 1
72 Shift Rod 1
73 Spring Pin 5×30 1
74 Gear Shift Markable Plate 1
No. Description
Qty
75 Bolt M6×16 4
76 Engine 1
77 Pulley 1
78 Key B5×4.76×40 1
79 Screw M8×12 2
80 Blade Mount Bracket 2
81 Pin B10×45 2
82 R Clip 2.5 2
83 Bolt M10×30 4
84 Blade 2 10
85 Swing Nut 4
86 Adjustable Side Shield 1 1
87 Bolt M8×20 12
88 Side Tine Shield 2
89 B Style Sprig Nut M8 2
90 Blade 1 2
91 Lock Nut M8 3
92 Bolt M8×25 3
93 Tine Shield 1
94 Spring 2
95 Pin 2
96 C-Clip 2
97 Handle Mount Bracket 2 1
98 Handle Mount Bracket 1 1
99 Handle Support Frame 1
100 Bolt M10×25 4
101 Nut M8 1
102 Uppder Handle 1
103 Lock Lever 1
104 Lever Knob 2
105 Bolt M8×85 1
106 Throttle Cable 1
107 Throttle Lever Assy. 1
108 Bolt M6×60 1
109 Lock Nut M6 1
110 Tensioner Pulley Cable 1
111 Pulley Cable Drag Rod 1
No. Description
Qty
1 Gear Box Assembly 1
2 Blot M8×20 1
3 Flat Washer 8 12
4 Gear Box Case Weldment (L) 1
5 Rubber Gasket 1
6 Wear-Resisting Gasket 1 2
7 Bushing I 1
8 End Cap 2
9 Chain 06B-50 1
10 Bushing II 1
11 Bearing Bushing 16×20×25 1
12 Drive Chain Z12 1
13 Gear Z56 1
14 Wear-Resisting Gasket 7 1
15 Thrust Washer 1
16 Wheel Shaft Bushing 1
17 Drive Shaft Weldment 1
18 Wear-Resisting Gasket 6 2
19 Bearing HK614 5
20 Wear-Resisting Gasket 3 3
21 Gear 4 1
22 Gear 1 1
23 C-Clip 16 3
24 Spline Shaft 1 1
25 Gear 5 1
26 Steel Ball 1/4" (6.35mm) 1
27 C-Clip 12 2
28 Spring 1
29 Poking Fork Weldment 1
30 Shift Fork 1
31 Bearing HK1620 3
32 Shift Fork Guide Pin 1
33 Bearing BK1614 1
34 Shaft 3 1
35 Gear Box Right Cover 1
36 Shaft 4 1
37 Flange Lock Nut M8 23
21
YT4565PM02 - 1704
|
Parts List
