No. Description
Qty
130 Adjustable Side Shield 2 1
131 Bolt M10×25 16
132 Spacer 3 1
133 Screw M5×10 4
134 Bolt M5×12 2
135 Long Bolt 1
136 Cabel Fixation Clamp 1
137 Belt Cover Mount Bracket 1
138 Belt Pulley 1
139 Lock Nut M5 2
140 Key A5×20 1
141 Depth Stake 1 1
142 Belt 4LXP1308 1
143 Depth Stake 2 1
144 Belt Cover 1
145 Left Wheel Assy 1
146 Spacer 2 1
147 Flange Lock Nut 10 5
No. Description
Qty
148 C-Clip 9 1
149 Tensioner Pulley 1
150 Bushing 1
151 Wheel Bracket Weldmen 1
152 Bolt 5/16 - 24 UNF*25 1
153 Spring Washer 8 1
154 Bolt M10×290 1
155 Counterweight 1 1
156 Bolt M8×40 4
157 Spacer 1 1
158 Tensioner Pulley Shaft 1
159 Bolt M8×30 1
160 Belt Block Rod 1
161 Big Flat Washer 8 2
162 Engine Protector Weldment 1
163 Spacer 4 1
No. Description
Qty
112 Bending Joint 1
113 End Cap 25 2
114 Upper Handle Sleeve 2
115 Brake Connecting Plate 1
116 Shift Lever Knob 1
117 Shift Lever 1
118 Bushing 1
119 Support Sleeve 1
120 Bolt M8×75 4
121 Spring 2
122 Pin Bracket 2
123 Rubber Cap 1
124 Serrated Rear Shield 1
125 Hinge 4
126 Hinge Shaft 1
127 Limiter Pin 1
128 Spring Washer 5 1
129 Bolt 1
22
Dual Rotating Rear Tine Tiller
»
Operator’s Manual
YT4565PM02 - 1704
Parts List
|
