YARDMAX YT5328 - Parts List

No. Description QTY.
1 Handlebar Grip 2
2 Upper Handlebar 1
3 Adjusting Hand Knob M8×25 3
4 Tensioning Pulley Cable 1
5 Inner Hexangular Screw M6×35 1
6 Flange Lock Nut M5 1
7 Drive Control Lever 1
8 Lever Bolt 1
9 Lock Nut M6 16
10 Bolt M8×25 8
11 Handlebar Adjusting Plate 2
12 Big Flat Washer 8 23
13 Lock Nut M8 15
14 Lower Handlebar 1
15 Bolt M8×45 3
16 Depth Stake 1
17 Wheel Cap (Black) 2
18 Belt 4LXP85 1
19 Bolt M6×20 1
20 Spring Washer 6 6
21 Large Flat Washer 6 1
22 Small Pulley 1
23 Flat Key A 5×5×30 1
24 Tensioning Pulley 1
25 Bolt M8×30 1
26 Washer 16 1
27 Spring Washer 8 11
28 Lock Ring 1
29 Bearing Bushing 1
30 Belt Guide Rod 1 2
31 Belt Guide Rod 2 1
32 Return Spring 1
33 Slide Bushing 1
34 Tensioning Pulley Swing Arm 1
35 Upper Belt Guard 1
No. Description QTY.
36 Bolt M10×100 2
37 Bolt M8×235 2
38 Bolt M6×16 5
39 Flat Washer 6 11
40 Bolt M6×40 2
41 Bolt M8×25 6
42 Bolt M8×20 1
43 Flat Washer 8 7
44 Belt Guard Mount Bracket 1
45 Gasoline Engine 156F 1
46 Bolt M8×40 3
47 Frame Weldment 1
48 Lock Nut M10 4
49 Big Flat Washer 10 4
50
Tine Shield - Left 1
51 Wheel Bushing 2
52 Wheel (Black) 2
53 Lock Nut M6 2
54 Tine Shield -Middle 1
55 Tine Shield - Right 1
56 Bolt M6×16 6
57 Pin B8×32 1
58 Clip 2.5 3
59 Cable Fixing Plate 1
60 Bolt M10×50 2
61 Inner Tine - Right 1
62 Pin 8×45 2
63 Outer Tine - Right 1
64 Transmission Case 1
65 Lower Belt Guard 1
66 Inner Tine - Left 1
67 Outer Tine - Left 1
68 Bearing Sheath 2
69 Screw M6×25 9
70 Oil Seal FB25×40×8 2
PARTS LIST
20
Front Tine Tiller
»
Operator’s Manual
YT5328PM01 - 1705
Parts List
|
