Yardworks 060-1784-4 User Manual

TABLE OF CONTENTS
Content Page
Safe Operation 3-6
Assembling the Lawn Mower 7-10
Description of Parts 11
Operating The Lawn Mower
12-15
Maintenance
18
Storage 19
Service 20
Troubleshooting 21
Warranty 22
Exploded View/Parts List
23-27
SPECIFICATIONS
Model Number 060-1784-4
Motor 24 V
Battery 24 V, 20 Ah lead-acid
Charge time approx. 15 hours
No-load Speed 3,300 RPM
Cutting Path 18” (45.7 cm)
Functions 2-in-1: mulch and rear bagging
Weight 85.8 lb (39 kg)
2
Slope Gauge and Operation 16-17
Height Adjustments
7 positions, 1 1/4 − 3 1/2” (3.2 − 8.9 cm)

Yardworks 060-1784-4 Specifications

General

Brand	Yardworks
Model	060-1784-4
Category	Lawn Mower
Language	English
